EF-CoreEnterprise Firewall Core
Enterprise-class 100 Gbps Cloud Gateway delivering 79 Gbps IDS/IPS, 22,500+ client capacity, and 5,000+ concurrent IPsec tunnels.
Overview
- Dimensions
- 442.4 x 43.7 x 400 mm (17.4 x 1.7 x 15.8")
- UniFi Application Suite
- Network
- Managed UniFi Devices
- 2,250+
- Simultaneous Users Connected
- 22,500+
Performance may be degraded with advanced gateway features (e.g., Traffic Identification)
- Max. WAN Port Count
- 8
- Default WAN Ports
- (1) 100G QSFP28 (1) 25G SFP28 (1) 10 GbE RJ45
- Port Layout
- 1 GbE RJ45: 2 (1G/100M/10M)
- 10 GbE RJ45: 8 (10G/5G/2.5G/1G/100M)
- 25G SFP28: 4 (25G/10G/1G)
- 100G QSFP28: 4 (100G/40G)
- MGMT: 1 (1G/100M/10M)
- Console: 1
- IDS/IPS Throughput
- 79 Gbps
- Capacity
- SSL/TLS Inspection Concurrent Sessions: 10,000
- Concurrent Sessions: 10 Million
- New Sessions / Second: 120,000
- Form Factor
- Rack mount (1U)
- Redundancy
- Shadow Mode (VRRP) Gateway Failover (2) Hot-Swappable PSUs
Security
- Stateful Firewall
- Yes
- Application-Aware Layer 7 Firewall
- Yes
- SSL Inspection & URL Filtering
- Yes
- DPI & Traffic Identification
- Yes
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
- Yes
- Content Filtering
- Yes
- Intrusion Prevention (IPS/IDS)
- Yes
- Ad Blocking
- Yes
- IDS/IPS Signatures
- 95,000+ with CyberSecure Enterprise
VPN & SD-WAN
- License-Free SD-WAN
- Yes
- Site-to-Site VPN
- Site Magic
- IPsec
- OpenVPN
- VPN Server
- Identity Endpoint One-Click VPN
- Teleport Zero-Configuration VPN
- WireGuard
- OpenVPN
- L2TP
- VPN Client
- OpenVPN
- WireGuard
Networking
- Multi-WAN Load Balancing
- Yes
- Shadow Mode (VRRP) High Availability
- Yes
- LACP Port Aggregation
- Yes
- Dynamic Routing
- OSPF
- BGP
- Advanced QoS
- Yes
- Multicast DNS (mDNS)
- Yes
- Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
- Yes
- Integrated RADIUS Server
- Yes
- RADIUS over TLS (RadSec)
- Yes
- Additional Internet Failover with UniFi LTE Backup
- Yes
- Internet Quality and Outage Reporting
- Yes
- MAC Address Table Size
- 130,000
- Policy-based WAN and VPN Routing
- Yes
- Customizable DHCP Server
- Yes
- IPv6 ISP Support
- Yes
- IGMP Proxy
- Yes
- All Traffic Flows
- Yes
Hardware
- Max. Power Consumption
- 171W
- Power Method
- Universal AC input, 100–240V AC, 7.5A Max., 50/60 Hz
- Power Supply
- (2) Hot-Swappable AC/DC 550W PSU
- Supported Voltage Range
- 100–240V AC
- Heat Dissipation
- 585 BTU/hr
- Processor
- 24-core ARM® v9 at 2.5 GHz
- System Memory
- 32 GB
- On-board Storage
- Integrated 128 GB SSD
- Weight
- 7.85 kg (17.31 lb)
- Enclosure Material
- Aluminium CNC, SGCC steel
- LCM Display
- 1.3" touchscreen
- Management
- Ethernet Bluetooth
- LEDs
- Ethernet
- SFP28
- QSFP28
- Swappable Fan
- CRPS
- Button
- (1) Factory reset
- ESD/EMP Protection
- Air: ± 8kV, contact: ± 4kV
- Ambient Operating Temperature
- 0 to 40° C (32 to 104° F)
- Ambient Operating Humidity
- 5 to 95% noncondensing
- NDAA Compliant
- Yes
- Certifications
- CE, FCC, IC
Software
- Application Requirements
- Mobile App: UniFi iOS™: Version 10.35.0 and later UniFi Android™: Version 10.38.1 and later
Specifications are provided by the manufacturer and may change without notice. Supplied, installed and supported by Ark Assist.
